What is P20 steel or P20 tool steel?

As we have heard P20 steel or P20 tool steel, whatever you would really like to say, tool steel grade equivalent, Corrosion Resistance vs p20

is basically low alloy steel, or chrome-moly alloy steel, Approximately having carbon content between 0.35 to 0.40.

As time goes on, many variations of basic P20 steel I.e, P20 tool steel chemical composition, have been introduced inside the marketplace. P20 tool steel chemical composition, P20 tool steel suppliers,p20 steel properties,p20 steel price,h13 tool steel

Every new modification has an impact on various techniques used in the fabrication of a mold.

P20 tool steel chemical composition,P20 tool steel suppliers,p20 steel properties,p20 steel price,h13 tool steel,Corrosion Resistance vs p20,tool steel grade equivalent
P20 tool steel chemical composition,h13 tool steel, Corrosion Resistance vs p20

Details of P20 steel.

The p20 steel specifications are given below:- P20 tool steel chemical composition, P20 tool steel suppliers,p20 steel properties

AISI- P20 steel

Class Plastic Mould Steel
Type Tool steel
Category Chrome Moly Alloy Steel
Grades

U.S           ASTM A681, AISI P20 Steel.

Germany   DIN 1.2311/1.2738Ni

Availability In Stock

What is p20 die steel?

Firstly, p20 die steel is a set of this steel. p20 steel price,h13 tool steel,tool steel grade equivalent,Corrosion Resistance vs p20

We use this p20 tool steel for the making of die for numerous uses like:-

  • die for plastic paver mold.
  • rubber paver mold. P20 tool steel chemical composition, P20 tool steel suppliers,p20 steel properties
  • for various die purposes

The simple Couse behind it is the p20 steel has good tensile power.

As it has good resistance against corrosion, so we generally have no problem using it for die purposes.

P20 tool steel chemical composition,P20 tool steel suppliers,p20 steel properties,p20 steel price,h13 tool steel,Corrosion Resistance vs p20,tool steel grade equivalent

What are the p20 steel properties?

The basic p20 steel properties description are as follows:-

  • P20 tool steel is normally pre-hardened between 29 to 33 HRC.
  • It has proper mirror polish-capability and its less texture makes finishing more simpler.
  • It maintains uniform hardness throughout even across large blocks.
  • Its excellent weld-ability with grate toughness and nitriding properties makes it a primary choice for plastic mold makers.

As P20 tool steel chemical composition is uniform. p20 steel properties,p20 steel price,h13 tool steel,Corrosion Resistance vs p20

that’s provides excellent machining and polishing ability.

You could buy from us at the lowest price.

What are the p20 steel applications?

There are various applications of p20 tool steel.

It has the best texture and good properties. it is randomly used for numerous purposes.

The various p20 steel applications are as follows:-

  • Used for various large-size Plastic Molds.
  • Precision plastic mold.
  • Cars accessories.
  • household items.
  • Electronic equipment plastic mold.

P20 tool steel chemical composition,P20 tool steel suppliers,p20 steel properties,p20 steel price,h13 tool steel,Corrosion Resistance vs p20,tool steel grade equivalent

What is p20 tool steel chemical composition?

The p20 tool steel is available in two groups.

and the p20 steel composition ar as follows:-

   Grades      C     Cr.     Fe.    Mg.     Mo.     P.      Si.      S.      Ni.
   1.2311 0.28-0.4 1.4-0.2 Balance 0.6-0.1 0.30-0.55 .03max  0.2-0.8 .03max .
 1.2738N 0.28-0.4 1.8-2.1 Balance 1.3-1.6 0.15-0.25 .03max  0.2-0.4 .03max 0.9-.1.2

What are the mechanical properties of P20 tool steel?

The mechanical properties of p20 tool steel are as described below:-

  • Plastic mold steel. it is generally supplied in quenched and tempered conditions.
  • Good machinability. P20 tool steel chemical composition, P20 tool steel suppliers,p20 steel properties,p20 steel price
  • Excellent polish capability, compared to 1.2312 (AISI P20+S). Similar to AISI P20.

As commonly delivered in the hardened and tempered state, hardness is normally 32HRC.

No hardening risks, no heat treatment, no distortion to tools. h13 tool steel,Corrosion Resistance vs p20,tool steel grade equivalent

Can be added Nitrided or flame hardened, Normally.

P20 tool steel chemical composition,P20 tool steel suppliers,p20 steel properties,p20 steel price,h13 tool steel,Corrosion Resistance vs p20,tool steel grade equivalent

What are the physical properties of P20 tool steel?

The fundamental physical properties of the best plastic mold steel are as follows:-

Density          0.284 lb/in3 (7861 kg/m3)
Specific Gravity              7.86
Modulus of Elasticity         30 x 106 psi (207 GPa)
Thermal conductivity         24 Btu/ft/hr/°F  41.5 W/m/°K
Machinability         60-65% of a 1% carbon steel

What is the coefficient of thermal expansion of best tool steel?

Coefficient Of Thermal Expansion
Temperature   ºF in/inºF x106 Temperature  ºC mm/mmºCx106
70-200 6.7 21-93 12.0
70-500 7.2 21-260 12.9
70-1000 7.6 21-538 13.7

What is the tempering temperature of p20 steel?

The tempering temperature of p20 tool steel plates are as noted under within the box :-

  Temperature            P20 tool steel
   ºF  ºC                   HRC
  400  204                 48 – 49
  600  316                 46 – 47
  800  427                 43 – 44
1000  538                 39 – 40
1100  593                 33 – 34
1150  621                 30 – 31
